Notice to our valued customers who use GP3000H option cable Rev. A
Posted: May. 13, 2014
Thank you very much for your continuous use of Pro-face products.
We have confirmed the option cable for GP3000H an operation manual has a written mistake.
The symptom and corrective measures for this problem are indicated below.
We sincerely apologize for any inconvenience this may cause you.
We have confirmed the option cable for GP3000H an operation manual has a written mistake.
The symptom and corrective measures for this problem are indicated below.
We sincerely apologize for any inconvenience this may cause you.
Symptom descriptions
The pin number, and an operation manual and a hardware manual of a common mode filter had disagreement. It does not start, if it connects with a pin number as an operation manual
Applicable combination of products
The followings are applicable products
Product model : | GP3000H-CBLS-3M |
---|---|
GP3000H-CBLS-5M | |
GP3000H-CBLH-10M | |
GP3000H-CBLS-10M | |
GP3000H-CBLSD232-10M | |
GP3000H-CBLSD232-3M | |
GP3000H-CBLSD422-10M | |
GP3000H-CBLSD422-3M | |
Product Revision: | Rev. A |
Common mode filter: | TDK RAMDA RSAL-2001W |
Photo: | ![]() |
Measures
Please wire as follows.

In addition, if improper connection is carried out, operation will not be carried out, but a product does not break down.
A new operation manual and a hardware manual are ending with web public presentation.
A new operation manual and a hardware manual are ending with web public presentation.
