| I want to operate an external PC via touch panel. |
|
|
|
|
|
|
Installing the Mouse Emulation software on the PC allows you to output GP touch coordinates to the PC using serial communication. You can control the PC's mouse cursor on the GP unit.
To use the Emulate Touch Output feature, the following items are required as well as an environment in which a PC screen can be displayed on the GP unit via VM unit.
- RS-232C crossing cable (commercial product)
- Mouse Emulation software (UPDD_30846P.EXE, free download from our website)
|
|
|
| NOTE |
| - |
Connect an RS-232C cable to COM1 on the touch panel unit. The connector on the touch panel unit is male-typed pin plug. |
|
|
|
|
|
