FAQ
Settings for daisy chain connection


Sharing video images between multiple devices via daisy chain connection, image quality may be deteriorated. In this case, turn off the termination switch on the VM unit when it is used as a relay, or turn on the switch when the VM unit is used as a terminal device. By doing so, you can reduce deterioration.



The termination switches are below the DVI-I terminals on the side panel of the VM unit. All of the 4 switches are set to "ON" by default.
