38.10.2.2 Window Frame - Right-click menu

Menu displays when right-clicking the WinGP window frame or clicking on the keypad . This menu is available when in the [System Settings] window, [Display Unit] area, IPC Settings tab, the [Display Right-Click Menu] check box is selected.

Screen Change

When you select [Screen Change], the [Select Display Screen] dialog box appears and allows you to switch the display screen.

Screen

Specifies the screen number to switch from 1 to 9999.

  • Only screens in the project can be opened in the Simulation.

Number

Displays the screen number.

Title

Displays the screen title.

Open

[Screen Number] field for selecting the screen to open. You can also use the screen number list to open a screen.

Close

[Select Display Screen] dialog box opens.

Offline (Online)

Switches to offline mode. If displaying in offline mode, switches to the online screen.

Full Screen Mode

Displays the full screen.

Minimized

Hides the window and displays the icon on the task bar.

Close

Exit WinGP.
